FUSEConnect® SC Splice-On Connectors from AFL are fusion-spliced, field-terminated connectors that are uniquely designed and feature just four components. With a factory pre-polished ferrule, its innovative field-termination process eliminates polishing, adhesives and crimping in the field minimizing the potential for operator error and expensive connector scrap.
FuseConnect utilizes a fusion splicer to terminate the connector in the field, addressing return loss concerns present in analog optical networks. This advanced process yields true APC performance of >65 dB return loss in an SC/APC configuration and SC single-mode is compliant to GR-326-CORE.
Designed to work with an industry standard 10 mm cleave length and splicers utilizing a fiber holder system, FuseConnect is compatible with Fujikura fusion splicers and most other fiber holder-based fusion splicing platforms.
FUSEConnect® SC Fusion-Spliced Connector Features
- Field installable
- Only four components
- No adhesives, crimping or polishing
- Compatible with most fusion splicers
|Insertion Loss||9/125 OS2||Average: 0.15 dB |
Max: 0.35 dB
|Return Loss||9/125 OS2||> 55 dB|
|Operating Temp.||-40°C to +75°C|
