| Front Panel Connector |
MTP/UPC Elite 8 Fiber | Rear Panel Connector |
MTP/UPC Elite 32 Fiber |
| Ferrule Type Front |
|
Ferrule Type Rear |
 |
| Front Cassette Ports |
4 | Rear Cassette Ports |
1 |
| Insertion Loss Maximum Side A |
≤0.35dB | Insertion Loss Maximum Side B |
≤0.35dB |
| Insertion Loss Typical |
0.10dB | Insertion Loss Typical |
0.10dB |
| Return Loss | ≥20dB | Return Loss | ≥20dB |
| =============== |
==================== | ================== |
================== |
| Cable Type |
OM4 50/125μm | Wavelength | 850/1300nm |
| Fiber Count | 32 | Fiber Grade | Corning ClearCurve Glass |
| Polarity | Straight (Type A) | Cable Outer Diameter | 250um |
| Cable Jacket | N/A | Sub Unit Outer Diameter | N/A |
| Bend Radius, No Load |
10x cable overall diameter | Bend Radius, Load |
15x cable overall diameter |
| =============== |
==================== | ================== |
================== |
| 40 GbE Distance Max. | 100 GbE Distance Max. | 40G-SWDM4 |
100G-SWDM4 |
| 150 Meter | 150 Meter | 400 Meter | 100 Meter |
| Operating Temperature | 0° to 70°C (32° to 158°F) | Storage Temperature | -40° to 70°C (-40° to 158°F) |
Specifications
