The LightWave Mode Conditionig  SC-LC Multimode OM1/Singlemode OS2 Fiber Optic Patch Cable is a Optical Mode Conditioning cable that incorporates Multimode 62.5/125 and Singlemode 9/125 glass to allow a Singlemode Transiever to communicate to a Multimode Tranceiver. This allows a reliable means of connecting an internal multimode fiber network with external singlemode 1000Base- LX based transmission. Mode conditioners provide a method of offsetting a single-mode fiber core with a corresponding multimode fiber. This calibrated offset reduces a phenomena called differential mode dispersion, or DMD, which can cause the transmitting laser pulse to spread out and merge into neighboring pulses creating bit errors in the transmission signal.

Mode conditioners are built as a duplex patch cable, and can easily be installed in a system without the need for additional components or hardware. Their length can range from one meter and up to support virtually any network topography.

All LightWave brand fiber optic patch cables are assembled to meet and exceed industry performance standards. Each product is individually tested to make sure you receive the highest possible quality, and the results of each test are included with the product.

Features

• Zip-cord duplex configuration
• OM1 62.5/125 micron glass
• OS2 9/129 micron glass
• High speed, low loss
• Orange OFNR-Rated (Riser) Jacket

Optical Characteristics
