ST/PC Fiber Optic Pigtail, 50/125 Multimode OM4, Tight Buffer 900um
MSRP:
$2.19 - $8.06
$1.46 - $5.38
Speak to one of our experts.
The OM4 ST Pigtail bundle comes in a pack of 12 ST fiber optic pigtails,each in a different color, including: Blue, Orange, Green, Brown, Slate, White, Red, Black Yellow, Violet, Rose, and Aqua. These pigtails each have an ST connector with a PC finish that helps to reduce reflective loss, which leads to better performance.
The ST connector has been a favorite for a variety of applications, thanks to its cost-effectiveness, ease in termination and low-loss connectivity. This item comes packaged in protective foam.
| Optical Characteristics | 50/125 OM4 | |
| Maximum Finished Cable Attenuation Coefficient | @850nm | 3.0 dB/km |
| @1300nm | 1.0 dB/km | |
| Overfill Launch Bandwidth | @850nm | 1500 MHz.km |
| @1300nm | 500 MHz.km | |
| Laser Bandwidth | @850 | 4700 MHz.km |
| Gigabit Ethernet Link Length (1 Gbps) | 1000 BASE-SX (850nm) | 1100 Meters |
| 1000 BASE-SX (1300nm) | 550 Meters | |
| Gigabit Ethernet Link Length (10 Gbps) | 1000 BASE-SX (1300nm) | 550 Meters |
