Acting as the backbone for most of todays fiber based systems, stranded fiber optic cables play a critical role in the high speed network. AFLs Non-Armored Loose Tube fiber optic cables are designed to provide high fiber counts with the flexibility and versatility required for todays most demanding installations.

Our cables feature fiber counts up to 576, compliance with EIA/TIA and REA/RUS PE-90, and are S-Z stranded for easy mid-span access. Industry standard designs combined with innovative technologies, such as a dry core product, yield a world class cable that will support todays and tomorrows technological needs.

Note: This item may require 24 hours for cut and prep before shipping.

• Part Number:
• LE0249C5101N1
• Fiber Count:
• 24
• Number Of Tubes/Fibers:
• 2w/12 (3 fillers)
• Nominal Diameter:
• Inches: 0.41
• Mm: 10.5
• Nominal Weight:
• Lbs/ 1000ft : 60
• (kg/km) : 90
• Maximum Tensile Load:
• Lbs (n):
• Short Term: 600 (2670)
• Long Term: 200 (890)
• Minimum Bend Radius::
• Inches (cm):
• Short Term: 8.2 (21.0)
• Long Term: 4.1 (11.0)

Product Applications:

• Long Haul Networking
• Building Interconnections (Campus LAN)
• Trunking Lines Direct to Telecommunications Closet
• Local Loop
• Distance Learning
• Distribution
• Intrabuilding Backbones

Temperature Range:

• Operating -40°C to +70°C
• Storage -40°C to +75°C
• Installation -30°C to +70°C
