Description
CF120 90° Horizontal Elbow Cover 120mm Fiber Duct Channel
Top cover for 90° 120mm horizontal elbow, yellow 120mm W x 100mm H, PVC Fiber duct channel.
Shaxon’s 120mm fiber duct accessories features rugged ABS construction and Pantone 1223c yellow color
Fiber duct certificates include:
- UL Cable Routing Assemblies and Communications Raceways
- Fire Retardant plastic, UL94-V0 rated
- CE (EN 61537:2007)
- RoHS
- SGS Reports (Light aging test, Steady heat and humidity test, Vertical burning)
Working temperature: -40 – 55
Fiber cable duct is designed to protect and route fiber optic patch cords, multi-fiber cable assemblies, and intrafacility fiber cables (IFC) to and from fiber splice enclosures, fiber distribution frames and fiber optic terminal devices.
Shaxon stocks a complete line of fiber duct products that feature a tool-less design for easy installation in the field. Built-in connectors on elbows, t’s and crosses plug directly into the duct sticks and connect with a simple screw and nut system. Other accessories attach with a simple coupler and the same easy to use hardware. Our duct sticks are fire retardant plastic, UL94-V0 rated and all accessories are rugged ABS plastic. Our certificates include:
- Conforms to UL 2024 Cable Routing Assemblies and Communications Raceways (E515097)
- CE (EN 61537:2007)
- RoHS
”Break it Down with Shaxon” -This is a simple, aesthetically pleasing, high quality yet very competitively priced option- reach out to today to find out how we can support you on your fiber duct needs!
