TE-8202A-W - Fiber Optic Fusion Splicer

Fiber Optic Fusion Splicer

List Price: $5,299.00
(You save $529.90 )

The splicing machine is a new fully-digital design with 5" LCD colorful display, provides the latest core to core alignment technology.

High quality fusion splicing

  • Auto/manual/full auto focus functions
  • Advanced core to core alignment
  • Average splice time: 10 seconds

Heat shrink protection

  • Suitable for 20/40/60mm (0.8/1.6/2.4") tubes
  • Average tube-heat time: 30 seconds

Hi-resolution output

  • 5" colorful LCD display
  • Separately X or Y axis views with 300 times magnification
  • Cutting-edge technology for image processing

Store 6000 groups of latest splicing results

USB port B-type for updates and result transfers

Removable and Rechargeable Li-ion battery with indicator will provide 180 times splicing and heating


Model No. TE-8202A
Applicable Fibers SM, MM, NZDS, EDF
Average Splice Loss 0.02dB(SM), 0.01dB(MM), 0.04dB(NZDS), 0.04dB(EDF)
Splice Time (sec.) 10 sec. (for SM fiber)
Return Loss =60dB
Diameter of fiber optic Cladding diameter:80-150µm , Coating diameter:100-1000µm
Tension Test 2.0N(200gf)(Standard)
Splicing Program 50 groups
Heat Shrinkable Tube 20mm, 40mm, 60mm
Memory Capacity 6000 memories
Battery low indication 4pcs led light indication
Environmental Conditions -10~+50°C (operation temperature),0~95% RH(humidity), 0~5000m(altitude)
Standard Package Fusion splicing machine, Fiber cleaver, Fiber stripper, Leak proof dispenser,
AC adaptor, Battery(in the machine), Spare electrodes, 60mm Shrinkable tube 25pcs,
Cooling tray, Quick reference guide, Carrying case with carrying strap
Power Supply AC adaptor: 100~240V input voltage, 50/60Hz; 15V, 4A
Standard plug A type
Battery 12V 5.2AH
Dimensions 5.1 x 5.3 x 5.1 inches
Weight 5.5 lbs (battery included)
