Fujikura 90R Mass Fusion Splicer

click to zoom in

Fujikura 90R Mass Fusion Splicer

Item#:
S017509
List Price: $13,916.60
$13,902.68
(You save $13.92 )
Condition:
New
Availability:
Lead Time: TBD / Contact Cables Plus USA for current availability. Ships from manufacturer Free Ground Shipping - Discounts not available for this product.
Weight:
27.00 LBS
Customer Service

Need Help?

Speak to one of our experts.

Fujikura 70R Fusion Splicer Kit

Fujikura 90R Mass Fusion Splicer

List Price: $13,916.60
$13,902.68
(You save $13.92 )

Fujikura 90R Mass Fusion Splicer

List Price: $13,916.60
$13,902.68
(You save $13.92 )

Fujikura 90R Fusion Splicer

The Fujikura 90R is the mass fusion splicer workhorse of the splicing world. As data demand continues to rise, the solution to handle the increased traffic is to increase fiber counts. As a result, fiber counts being utilized in enterprise data centers, campus, and metro networks have grown enough to make single fiber splicing too costly and timely. High density cabling made possible by SpiderWeb Ribbon® (SWR®) and others like it are spurring ribbon splicing activity in places that have traditionally used loose fiber. The 90R is the answer to these changes in splicing demand.

With automated splice start, tube heater, wind protector, cleave tracking, and blade rotations for up to 2 cleavers at a time, this splicer frees up operator time for other fiber preparation steps. With 16-fiber add-ons, the Fujikura 90R splicer enables customers to successfully splice 16-count ribbon fibers with a 200 µm pitch and size.

With the Fujikura 90R, you can keep your splicer in the field longer with field replaceable V-grooves. When V-grooves can no longer be cleaned after extended use, or are accidentally damaged, you can resume splicing in minutes by installing the spare set included with your 90R kit.

 With the AFL Tote Solution installed, the 90R transit case securely integrates with Milwaukee's PACKOUT™ system, offering faster transport, stability, and time-savings for contractors and technicians.

Features:

  • Cleaver tracking and upkeep with wireless communication
  • Automated wind protector, tube heater and splice operation
  • User replaceable v-grooves
  • 200 μm and 250 μm SWR universal ribbon prep accessories
  • Graphical User Interface with 5.0" Touchscreen
  • PC software and 90R manual downloaded from splicer
  • Multi-function transit case with integrated workstation

Applications:

  • Data Center cable installation
  • High fiber count metro and
    campus networks
  • Long-haul network installs and repair
  • Trunk cable repair with Splice-on MPOs
  • Ribbon splicing high density cables with
    200 μm loose fiber
