LC/PC Fiber Optic Pigtail, Multimode OM3

click to zoom in

LC/PC Fiber Optic Pigtail, Multimode OM3

Item#:
FPT-OM3-LC-1M-BL
List Price: $3.05
$2.30
(You save $0.75 )
Condition:
New
Availability:
7 – 10 Day Lead-Time
Weight:
0.05 LBS
Customer Service

Need Help?

Speak to one of our experts.

FPT-OM3-LC - LC/PC Fiber Optic Pigtail, Multimode OM3, Tight Buffer 900um

LC/PC Fiber Optic Pigtail, Multimode OM3

List Price: $3.05
$2.30
(You save $0.75 )

LC/PC Fiber Optic Pigtail, Multimode OM3

List Price: $3.05
$2.30
(You save $0.75 )

With the OM3 Multimode LC Fiber Optic Pigtail, you can count on low transmission loss and easy installation to get your task completed faster. At half the size of the ST ferrule, the LC connector's compact design is great for saving on space. The connector has a PC finish to reduce reflection loss. With the LC pigtail, you can take on any number of applications, including military active device termination and fusion splicing.



With OM3 fiber optics, experience data transfers over a 1Gbps link with a 50/125 micron glass fiber over a distance of up to 1000 meters at a wavelength of 850nm, and over a distance of up to 550 meters at 1300nm. For a 10Gbps link, you can transfer data over a distance of up to 300 meters at 850nm.

Choose from a selection of 12 colors, including blue, orange, green, brown, slate, white, red, black, yellow, violet, rose, and aqua.

All of our fiber optic pigtails are tested to ensure quality and performance that meet industry standards, and the test results for each pigtail are included with your purchase.



OM3 LC Fiber Optic Pigtail Optical Characteristics

Optical Characteristics 50/125 OM3
Maximum Finished Cable Attenuation Coefficient @850nm 3.0 dB/km
@1300nm 1.0 dB/km
Overfill Launch Bandwidth @850nm 1500 MHz.km
@1300nm 500 MHz.km
Laser Bandwidth @850 2000 MHz.km
Gigabit Ethernet Link Length (1 Gbps) 1000 BASE-SX (850nm) 1000 Meters
1000 BASE-SX (1300nm) 550 Meters
Gigabit Ethernet Link Length (10 Gbps) 1000 BASE-SX (1300nm) 300 Meters

LC OM3 Fiber Optic Pigtail Features

  • Simplex Configuration
  • LC Connector
  • OM3 50/125µm fiber glass
  • Riser Rated
  • Available in lengths of 1 to 10 meters
