Base Product Data

RapidNet Ultra12 - LC - MTP Elite Tethered Cassette - 12F Multimode OM4

Product Description:

RapidNet ULTRA12 Tethered Cassettes are designed to facilitate transition from a single MTP connector into small form factor (SFF)or very small form factor (VSFF) connectivity patching array. Cassettes are factory terminated and tested offering best in class ultra low loss connectivity for rapid deployment of ULTRA12 fiber systems, supporting the increasing demand on
parallel optics. Tethered Cassettes offer lower insertion loss compared to typical cassette and backbone cable configurations.
The compact design allows for a ultra high density installations to be realized, maximizing critical connectivity real estate. RapidNet ULTRA12 Cassettes are designed to be compatible with future VSFF connectors such as CS and SN which will take the fiber capacity from 12 fibers (LC) to either 18 fibers (CS) or 24 fibers (SN). Tethered cables can be produced to your required length with single or double jacket constructions. Tethered cassettes are made with 3.0mm single jacket cables which contain Corning® SMF-28® fibers for Singlemode and ClearCurve® fibers for Multimode.

Features and Benefits:

• High fiber density: LC 12F, CS 18F, SN 24F per cassette
• Custom length MTP Elite tethered cable
• Reduced insertion loss performance
• Factory terminated & tested
• Best in class ultra-low loss connectivity
• Effortless plug & play system
• Optional bare end for on-site splicing UL94 V0 compliant
• 3.0mm Single jacket or (Special Order) 4.5x0.5mm Double Jacket options
• Singlemode made with Corning® SMF28® Fibers
• Multimode made with Corning® ClearCurve® Fibers
