The Light Connection multi-tube Dry Loose Tube Indoor Outdoor Cable is composed of eight and twelve buffer tubes, water blocking yarn, a central strength member, an aramid ripcord, and a PVDF outer jacket. Each buffer tube consists of a 12 colored glass fibers and water-swellable yarn with a PVDF jacket 2.5mm in diameter. All component materials meet the EU RoHS and REACH Directive standards. Buffer tubes may be color-coded or sequentially numbered.
TLC S09DL96CZNPBL25 96 Fiber Dry Loose Tube is available in carbon black or special order colors (including 12 TIA standard colors). UL Listed OFNP cables are available, and unrated cables may be supplied to accommodate special needs. Standard surface print denotes construction, NEC rating, and fiber type, and includes footage markers.
This 96 fiber, SM cable is rated for an indoor/outdoor campus environment. It is a micro distribution, Data Center High Density, Plenum rated cable, jacketed in Black with 12.0mm OD - 2.5mm subs.
FEATURES
- Glass Type: Corning® SMF-28® Ultra
- Gel-Free waterblocking design
- UV protected rugged jacket
- 96 & 144 Fiber count
- Plenum (OFNP) NFPA 262 (UL 910)
- Available in all fiber types
- Meets the application requirement of National Electric Code (NEC) Article 770 and are OFNP - rated.
Applications
- Plenum
- Duct
- Indoor/Outdoor
