Breakout Cable, MTP® 16 Elite/APC to LC EZConn Uni-Boot, OM5 Multimode 50/125 Micron, 16 Fiber

Breakout Cable, MTP® 16 Elite/APC to LC EZConn Uni-Boot, OM5 Multimode 50/125 Micron, 16 Fiber

Item#:
MTF-LCU-16-OM5-001MB
List Price: $143.69
$95.79
(You save $47.90 )
Availability:
Made To Order, Normal lead-time 15 - 21 Days ARO
Weight:
0.25 LBS
Bulk Pricing:
Buy in bulk and save
Customer Service

Need Help?

Speak to one of our experts.

Breakout Cable, MTP® 16 Elite/APC to LC EZConn Uni-Boot, OM5 Multimode 50/125 Micron, 16 Fiber

Breakout Cable, MTP® 16 Elite/APC to LC EZConn Uni-Boot, OM5 Multimode 50/125 Micron, 16 Fiber

List Price: $143.69
$95.79
(You save $47.90 )

Breakout Cable, MTP® 16 Elite/APC to LC EZConn Uni-Boot, OM5 Multimode 50/125 Micron, 16 Fiber

List Price: $143.69
$95.79
(You save $47.90 )

MTP®/MPO Fanout Cable Assemblies

MTP® 16 Elite Female to LC EZConn Uni-Boot Female, 16 Strand, Corning Clear Curve Multimode 50/125 Micron, OM5, OFNP Lime Jacket

MTP® Connectors

US Conec offers a full suite of MTP® brand MPO connectors and solutions for a variety of applications and operating environments. The MTP® connector design offers novel patented features, enhanced precision, proven reliability, and significant performance improvements compared to the standard MPO connector format.

LC/UPC Uniboot Ezconn Connector (Polarity Reversal)

LC Switchable Uniboot connector in a unique connector offering that allows for the use of a single round cable for duplex applications, a tool less polarity reversing feature.

Precision Optical Components

At the heart of every fiber to fiber and fiber to device interconnect is a precision optical interconnect component.  US Conec is dedicated to driving the next generation of optical links from source to detector by utilizing state of the art precision component design, metrology and manufacturing to produce low loss, cost effective ferrules and optical components optimized with the entire link in mind.  Sub-micron component modeling, design, production, measurement and testing are at the heart of US Conec’s engineering focused approach to solving real world communication problems every day.

Precision optical interconnect solutions include:

  • Low-loss, MT Elite® multi-fiber ferrules
  • LC Uniboot ferrules
  • FTTx hardened connector cabling infrastructure
  • MTP® brand MPO cable assemblies
  • Optical backplane connectivity for OBO architectures
  • Standards Compliance IEC 61754-5
  • Standards Compliance IEC 61754-7-1; 61754-7-2
  • Standards Compliance TIA 604-5

Specifications

  • Simplex 3.0mm cable
  • 50/125um OM5 Corning ClearCurve Glass
  • Plenum-Rated OFNP Aqua Jacket
  • 16-Fiber count
  • Nominal Diameter: 3.0m
  • Bend Radius: 1.8in (Installation), 1.2in (Long-term)

Connector Side A
MTP/APC Elite Low Loss 16 Fiber Connector Side B

(8) LC Uniboot

Ferrule Type Side A

Ferrule Type Side A

Ferrule Type Side B

Insertion Loss Maximum Side A
≤0.35dB Insertion Loss Maximum Side B
≤0.20dB
Insertion Loss Typical
0.10dB Insertion Loss Typical
0.08dB
Return Loss ≥0dB Return Loss ≥0dB
===============
==================== ==================
==================
Cable Type
OM5 50/125μm Wavelength 850/1300nm
Fiber Count 16 Fiber Grade
Polarity Type A, B & C available Cable Outer Diameter 3.0mm
Cable Jacket OFNP Plenum Sub Unit Outer Diameter N/A
Bend Radius, No Load
10x cable overall diameter Bend Radius, Load
15x cable overall diameter
===============
==================== ==================
==================
1 GbE Distance Max. 10 GbE Distance Max. 40 GbE Distance Max. 100 GbE Distance Max.
1,100 Meters 300 Meter 100 Meter 100 Meter
=============== ==================== ================== ==================
Operating Temperature 0° to 70°C (32° to 158°F) Storage Temperature -40° to 70°C (-40° to 158°F)
