Breakout Cable, MTP® Elite/UPC to LC Ezconn Uniboot, OM5 MM, 12 Fiber

List Price: $92.42

$61.61

(You save $30.81 )

Description
Downloads

Description

MTP® Elite Female to LC EZConn Uni-Boot Female, 12 Strand, Corning Clear Curve OM5 Multimode 50/125 Micron, OFNP Lime Green Jacket

MTP^® Connectors

US Conec offers a full suite of MTP^® brand MPO connectors and solutions for a variety of applications and operating environments. The MTP^® connector design offers novel patented features, enhanced precision, proven reliability, and significant performance improvements compared to the standard MPO connector format.

LC/UPC Uniboot Ezconn Connector (Polarity Reversal)

LC Switchable Uniboot connector in a unique connector offering that allows for the use of a single round cable for duplex applications, a tool less polarity reversing feature.

Precision Optical Components

At the heart of every fiber to fiber and fiber to device interconnect is a precision optical interconnect component. US Conec is dedicated to driving the next generation of optical links from source to detector by utilizing state of the art precision component design, metrology and manufacturing to produce low loss, cost effective ferrules and optical components optimized with the entire link in mind. Sub-micron component modeling, design, production, measurement and testing are at the heart of US Conec’s engineering focused approach to solving real world communication problems every day.

Precision optical interconnect solutions include:

Low-loss, MT Elite® multi-fiber ferrules
LC Uniboot ferrules
FTTx hardened connector cabling infrastructure
MTP® brand MPO cable assemblies
Optical backplane connectivity for OBO architectures
Standards Compliance IEC 61754-5
Standards Compliance IEC 61754-7-1; 61754-7-2
Standards Compliance TIA 604-5

Specifications

Simplex 3.0mm cable
50/125um OM5 Corning ClearCurve Glass
Plenum-Rated OFNP Erika Violet Jacket
12-Fiber count
Nominal Diameter: 3.0mm
Bend Radius: 1.8in (Installation), 1.2in (Long-term)

Connector Side A	MTP/UPC Elite Low Loss 8 Fiber	Connector Side B	(6) LC Uniboot
Ferrule Type Side A		Ferrule Type Side B
Insertion Loss Maximum Side A	≤0.35dB	Insertion Loss Maximum Side B	≤0.20dB
Insertion Loss Typical	0.10dB	Insertion Loss Typical	0.08dB
Return Loss	≥0dB	Return Loss	≥0dB
===============	====================	==================	==================
Cable Type	OM5 50/125μm	Wavelength	850/1300nm
Fiber Count	12	Fiber Grade
Polarity	Type A, B & C available	Cable Outer Diameter	3.0mm
Cable Jacket	OFNP Plenum	Sub Unit Outer Diameter	N/A
Bend Radius, No Load	10x cable overall diameter	Bend Radius, Load	15x cable overall diameter
===============	====================	==================	==================
1 GbE Distance Max.	10 GbE Distance Max.	40 GbE Distance Max.	100 GbE Distance Max.
1,100 Meters	300 Meter	100 Meter	100 Meter
===============	====================	==================	==================
Operating Temperature	0° to 70°C (32° to 158°F)	Storage Temperature	-40° to 70°C (-40° to 158°F)
