HD8² Cassette, 24 Strand, 50/125 OM4, CS/UPC (12) Port, Aqua Duplex, Front - (2) Port MTP Elite 12 Fiber Rear, Male Aqua, Straight (Type A) Pinout

click to zoom in
HD8² Cassette, 24 Strand, 50/125 OM3, MDC/UPC (12) Port, Aqua Duplex, Front - (1) Port MTP Elite 24 Fiber Rear, Male Aqua, Straight (Type A) Pinout
HD8² Cassette, 24 Strand, 50/125 OM4, CS/UPC (12) Port, Aqua Duplex, Front - (2) Port MTP Elite 12 Fiber Rear, Male Aqua, Straight (Type A) Pinout
HD8² Cassette, 24 Strand, 50/125 OM4, CS/UPC (12) Port, Aqua Duplex, Front - (2) Port MTP Elite 12 Fiber Rear, Male Aqua, Straight (Type A) Pinout
HD8² Cassette, 24 Strand, 50/125 OM4, CS/UPC (12) Port, Aqua Duplex, Front - (2) Port MTP Elite 12 Fiber Rear, Male Aqua, Straight (Type A) Pinout
HD8² Cassette, 24 Strand, 50/125 OM4, CS/UPC (12) Port, Aqua Duplex, Front - (2) Port MTP Elite 12 Fiber Rear, Male Aqua, Straight (Type A) Pinout
HD8² Cassette, 24 Strand, 50/125 OM4, CS/UPC (12) Port, Aqua Duplex, Front - (2) Port MTP Elite 12 Fiber Rear, Male Aqua, Straight (Type A) Pinout
HD8² Cassette, 24 Strand, 50/125 OM4, CS/UPC (12) Port, Aqua Duplex, Front - (2) Port MTP Elite 12 Fiber Rear, Male Aqua, Straight (Type A) Pinout

HD8² Cassette, 24 Strand, 50/125 OM4, CS/UPC (12) Port, Aqua Duplex, Front - (2) Port MTP Elite 12 Fiber Rear, Male Aqua, Straight (Type A) Pinout

Item#:
HDC-4CSME02SE2M12
List Price: $531.03
$479.85
(You save $51.18 )
Condition:
New
Availability:
Made To Order, Normal lead-time 7 - 10 days, after Drawing Approval
Weight:
0.20 LBS
Customer Service

Need Help?

Speak to one of our experts.

Phone Icon

804-716-9007

HD8² Cassette, 24 Strand, 50/125 OM3, MDC/UPC (12) Port, Aqua Duplex, Front - (1) Port MTP Elite 24 Fiber Rear, Male Aqua, Straight (Type A) Pinout

HD8² Cassette, 24 Strand, 50/125 OM4, CS/UPC (12) Port, Aqua Duplex, Front - (2) Port MTP Elite 12 Fiber Rear, Male Aqua, Straight (Type A) Pinout

List Price: $531.03
$479.85
(You save $51.18 )
⚠️ California Proposition 65 Warning: Some products sold on this site may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. Learn more: P65Warnings.ca.gov
Description
High Density Cassette, 24 Strand, Multimode 50/125 OM4, Front Panel includes 12-Port / 24-Fiber Violet CS/UPC, Rear Panel includes 2-Port Violet MTP Elite 12 Fiber Rear, Straight (Type A) Pinout

Product Specification:
Connector Side A
 CS/UPC Connector Side B
 MTP/UPC Elite Low Loss 12 Fiber
Ferrule Type Side A 1.25mm Ferrule Type Side B
 HDC-4CSME02SE2M12 - HD8² High Density Cassette, 50/125 OM4, CS/UPC (12) Port, Aqua Duplex, Front - (2) Port MTP Elite 12 Fiber Rear, Male Aqua, Straight (Type A) Pinout - Image 2HDC-4CSME02SE2M12 - HD8² High Density Cassette, 50/125 OM4, CS/UPC (12) Port, Aqua Duplex, Front - (2) Port MTP Elite 12 Fiber Rear, Male Aqua, Straight (Type A) Pinout - Image 3
Port Count Front
 12 Port Count Rear
 2
Insertion Loss Maximum Side A
 ≤0.20dB Insertion Loss Maximum Side B
 ≤0.35dB
Insertion Loss Typical
 0.08dB Insertion Loss Typical
 0.10dB
Return Loss ≥20dB Return Loss ≥20dB
===============
 ==================== ==================
 ==================
Cable Type
 OM4 50/125μm Wavelength 850/1300nm
Fiber Count 24 Fiber Grade Corning ClearCurve Glass
Polarity Straight (Type A) Cable Outer Diameter 900um
Cable Jacket OFNP Plenum Sub Unit Outer Diameter N/A
Bend Radius, No Load
 10x cable overall diameter Bend Radius, Load
 15x cable overall diameter
===============
 ==================== ==================
 ==================
40 GbE Distance Max. 100 GbE Distance Max. 40G-SWDM4 100G-SWDM4
150 Meter 150 Meter 400 Meter 100 Meter
Operating Temperature 0° to 70°C (32° to 158°F) Storage Temperature -40° to 70°C (-40° to 158°F)
