HD8² Cassette, 96 Strand, OM4, 8 Port MTP® Elite 12F (Male) Front to 4 Port MTP® Elite 24F (Male) Rear, Violet, Straight

click to zoom in
HDC-4MME812SE4M24 - HD8² Cassette, OM4, 8 Port MTP Elite 12F (Male) Front - 4 Port MTP Elite 24F (Male) Rear, Violet, Straight (Type A) Pinout - Image 13
HD8² Cassette, 96 Strand, OM4, 8 Port MTP® Elite 12F (Male) Front to 4 Port MTP® Elite 24F (Male) Rear, Violet, Straight
HD8² Cassette, 96 Strand, OM4, 8 Port MTP® Elite 12F (Male) Front to 4 Port MTP® Elite 24F (Male) Rear, Violet, Straight

HD8² Cassette, 96 Strand, OM4, 8 Port MTP® Elite 12F (Male) Front to 4 Port MTP® Elite 24F (Male) Rear, Violet, Straight

Item#:
HDC-4MME812SE4M24
List Price: $1,069.68
$802.26
(You save $267.42 )
Availability:
Made To Order, Normal lead-time 7 - 10 days, after Drawing Approval
Weight:
0.20 LBS
Customer Service

Need Help?

Speak to one of our experts.

Phone Icon

804-716-9007

HDC-4MME812SE4M24 - HD8² Cassette, OM4, 8 Port MTP Elite 12F (Male) Front - 4 Port MTP Elite 24F (Male) Rear, Violet, Straight (Type A) Pinout - Image 13

HD8² Cassette, 96 Strand, OM4, 8 Port MTP® Elite 12F (Male) Front to 4 Port MTP® Elite 24F (Male) Rear, Violet, Straight

List Price: $1,069.68
$802.26
(You save $267.42 )
Description
HD8² Cassette, 96 Strand, Multimode OM4 50/125um, Front Panel includes 8 Port Aqua MTP® Elite 12 Fiber Male, Rear Panel includes 4 Port Aqua MTP® Elite 24 Fiber Male, Straight (Type A) Pinout

Product Specification:

Front Panel Connector
 MTP/UPC Elite 12 Fiber Rear Panel Connector
 MTP/UPC Elite 24 Fiber
Ferrule Type Front

HDC-4MME812SE4M24 - HD8² Cassette, OM4, 8 Port MTP Elite 12F (Male) Front - 4 Port MTP Elite 24F (Male) Rear, Violet, Straight (Type A) Pinout - Image 2HDC-4MME812SE4M24 - HD8² Cassette, OM4, 8 Port MTP Elite 12F (Male) Front - 4 Port MTP Elite 24F (Male) Rear, Violet, Straight (Type A) Pinout - Image 3

HDC-4MME812SE4M24 - HD8² Cassette, OM4, 8 Port MTP Elite 12F (Male) Front - 4 Port MTP Elite 24F (Male) Rear, Violet, Straight (Type A) Pinout - Image 4HDC-4MME812SE4M24 - HD8² Cassette, OM4, 8 Port MTP Elite 12F (Male) Front - 4 Port MTP Elite 24F (Male) Rear, Violet, Straight (Type A) Pinout - Image 5

HDC-4MME812SE4M24 - HD8² Cassette, OM4, 8 Port MTP Elite 12F (Male) Front - 4 Port MTP Elite 24F (Male) Rear, Violet, Straight (Type A) Pinout - Image 6HDC-4MME812SE4M24 - HD8² Cassette, OM4, 8 Port MTP Elite 12F (Male) Front - 4 Port MTP Elite 24F (Male) Rear, Violet, Straight (Type A) Pinout - Image 7

HDC-4MME812SE4M24 - HD8² Cassette, OM4, 8 Port MTP Elite 12F (Male) Front - 4 Port MTP Elite 24F (Male) Rear, Violet, Straight (Type A) Pinout - Image 8HDC-4MME812SE4M24 - HD8² Cassette, OM4, 8 Port MTP Elite 12F (Male) Front - 4 Port MTP Elite 24F (Male) Rear, Violet, Straight (Type A) Pinout - Image 9

 Ferrule Type Rear
 HDC-4MME812SE4M24 - HD8² Cassette, OM4, 8 Port MTP Elite 12F (Male) Front - 4 Port MTP Elite 24F (Male) Rear, Violet, Straight (Type A) Pinout - Image 10HDC-4MME812SE4M24 - HD8² Cassette, OM4, 8 Port MTP Elite 12F (Male) Front - 4 Port MTP Elite 24F (Male) Rear, Violet, Straight (Type A) Pinout - Image 11HDC-4MME812SE4M24 - HD8² Cassette, OM4, 8 Port MTP Elite 12F (Male) Front - 4 Port MTP Elite 24F (Male) Rear, Violet, Straight (Type A) Pinout - Image 12HDC-4MME812SE4M24 - HD8² Cassette, OM4, 8 Port MTP Elite 12F (Male) Front - 4 Port MTP Elite 24F (Male) Rear, Violet, Straight (Type A) Pinout - Image 13
Front Cassette Ports
 8 Rear Cassette Ports
 4
Insertion Loss Maximum Side A
 ≤0.35dB Insertion Loss Maximum Side B
 ≤0.35dB
Insertion Loss Typical
 0.10dB Insertion Loss Typical
 0.10dB
Return Loss ≥20dB Return Loss ≥20dB
===============
 ==================== ==================
 ==================
Cable Type
 OM4 50/125μm Wavelength 850/1300nm
Fiber Count 96 Fiber Grade Corning ClearCurve Glass
Polarity Straight (Type A) Cable Outer Diameter 250um
Cable Jacket N/A Sub Unit Outer Diameter N/A
Bend Radius, No Load
 10x cable overall diameter Bend Radius, Load
 15x cable overall diameter
===============
 ==================== ==================
 ==================
40 GbE Distance Max. 100 GbE Distance Max. 40G-SWDM4
 100G-SWDM4
150 Meter 150 Meter 400 Meter 100 Meter
Operating Temperature 0° to 70°C (32° to 158°F) Storage Temperature -40° to 70°C (-40° to 158°F)
