OWL MPO-KIT- DataCenter 12 Series MPO Loss Test Kits
Features the flexibility to test, measure, and certify MPO cabling as well as one fiber at a time!
Features:
- Convenient power / loss measurement of 12-fiber MPO cables and links
- Ensure compliance to industry standards with PASS/FAIL certification
- Multimode / Singlemode ready
- Industry-first “label-to-cable” methodology
- Print durable labels directly to wireless label printers
- Store test results for later retrieval and report printing
- Quick check mode to verify output power from multi-fiber transceivers
- Shuttered MPO port helps prevent accumulation of debris in MPO port
- Unique feature to also test/certify single-fiber cables in same unit
- Stable and accurate output power into 12-fiber MPO cables and links
- Multimode & Singlemode versions available
- Single & Dual-wavelength versions available
- Auto-wavelength switching & manual source switching
- Shuttered MPO port helps prevent accumulation of debris in MPO port
- Separate single-fiber port for easy single-fiber testing
Applications:
- MPO backbone cable measurement *
- MPO link measurement *
- MPO cable acceptance testing *
- Traditional single-fiber testing *†
- Multi-fiber transceiver power measurement
* - requires separate MPO source or optical switch
† - with separate single-fiber source
