FUSEConnect® LC Splice-On Connectors from AFL are fusion-spliced, field-terminated connectors that are uniquely designed and feature just four components. With a factory pre-polished ferrule, its innovative field-termination process eliminates polishing, adhesives and crimping in the field minimizing the potential for operator error and expensive connector scrap.
FuseConnect utilizes a fusion splicer to terminate the connector in the field, addressing return loss concerns present in analog optical networks. Designed to work with an industry standard 10 mm cleave length and splicers utilizing a fiber holder system, FuseConnect is compatible with Fujikura fusion splicers and most other fiber holder-based fusion splicing platforms.
FUSEConnect® LC Fusion-Spliced Connector Features
- Field installable
- Only four components
- No adhesives, crimping or polishing
- True APC performance
|Insertion Loss||50/125 OM3/OM4||Average: 0.10 dB |
Max: 0.3 dB
|Return Loss||50/125 OM3/OM4||> 30 dB|
|Operating Temp.||-40°C to +75°C|
