OCC, DX, 12-Strand, 900um Tight Buffd, In/Out, Broadcast Rated, OS2, 9/125, SM, Black
- Broadcast cables are made in a variety of colors for easy identification or to blend in to the environment
- 2 to 24 fibers, higher fiber counts are available on request
- Distribution Broadcast fiber optic cables are immune to electro-magnetic and radio frequency interference
- Helically stranded cable core for flexibility, survival in difficult pulls, and excellent mechanical protection for the optical fibers
- Cables are suitable for use with single, as well as, multichannel connectors
- Excellent crush resistance to withstand crowd and vehicle traffic
- High tensile load rating for quick deployment and retrieval
- Lightweight Riser and Plenum cables are ideally suited for stadium and arena venues for video-on-demand applications. Interlocking armor cable options also available for stadium and arena venues
- Water-resistant and UV-resistant for extreme environments
- Outdoor, field proven cables are easily deployed and retrieved for remote news gatherings and sporting events
Note: This item may require 24 hours for cut and prep before shipping.
|
Field |
Riser |
Plenum (S Jacket) |
Plenum(K Jacket) |
Operating Temperature |
-55°C to +85°C |
-40°C to +85°C |
-20°C to +85°C |
-40°C to +85°C |
Storage Temperature |
-70°C to +85°C |
-55°C to +85°C |
-40°C to +85°C |
-40°C to +85°C |
Crush Resistance |
440 N/cm |
1,800 N/cm |
1,500 N/cm |
1,500 N/cm |
Impact Resistance |
200 impacts |
1,500 impacts |
1,000 impacts |
1,000 impacts |
Flex Resistance |
2,000 cycles |
2,000 cycles |
1,000 cycles |
1,000 cycles |
These specifications are subject to change without prior notification.
|
