TAA Compliant Fiber Patch Cable, ST-SC Fiber Patch Cable, Singlemode 9/125 OS2, UPC, Duplex

TAA Compliant Fiber Patch Cable, ST-SC Fiber Patch Cable, Singlemode 9/125 OS2, UPC, Duplex

Item#:
791415OS2D001MR3
List Price: $11.75
$7.83
(You save $3.92 )
Condition:
New
Weight:
0.15 LBS
Customer Service

Need Help?

Speak to one of our experts.

ST-SC Fiber Patch Cable, Singlemode 9/125 OS2, UPC, Duplex, yellow

TAA Compliant Fiber Patch Cable, ST-SC Fiber Patch Cable, Singlemode 9/125 OS2, UPC, Duplex

List Price: $11.75
$7.83
(You save $3.92 )

TAA Compliant Fiber Patch Cable, ST-SC Fiber Patch Cable, Singlemode 9/125 OS2, UPC, Duplex

List Price: $11.75
$7.83
(You save $3.92 )

The LightWave ST-SC Singlemode OS2 Fiber Optic Patch Cable is a perfect combination of high performance, low data loss and cost efficiency. When it comes to telecommunications applications, this is a cable that can easily match the demands of your business and budget.



The ST-SC fiber optic cable has a UPC finish with twist-lock bayonet coupling mechanism on the ST connector end, and a push-pull coupling mechanism on the SC end. Send data over a 9/125 micron glass fiber 1Gbps link a distance of up to 10,000 meters at a wavelength of 1310nm. For a 10Gbps link, you can transfer data a distance of up to 5,000 meters at a 1310nm wavelength or up to 30,000 meters at a 1550nm wavelength.

This ST-SC singlemode cable, along with all other LightWave brand fiber optic patch cables, is assembled to meet and exceed industry performance standards, and each product is individually tested to make sure you receive the highest possible quality, and those test results will be included with your cable.



Features

  • Singlemode for fast, long-distance data transfer
  • Duplex configuration
  • Low data loss
  • SC connector push-pull, key-oriented coupling mechanism
  • ST connector twist-lock bayonet coupling design



Optical Characteristics

Fiber Description & Type Typical Attenuation (dB/km)) 1 Gbps Ethernet Distance (Meters) 10 Gbps Ethernet Distance (Meters)
Singlemode, Tight Buffer 1310nm 1383nm 1550nm 1625nm 1310nm 1310nm 1550nm
900 Micron 0.65 --- 0.65 --- 10,000 5,000 30,000
2mm/3mm Breakout 1.00 --- 1.00 --- 10,000 5,000 30,000



Part Numbering

Additional Information

Standard Length Options

Obsolete Part Numbers

• 791414OS2D001MR3 (1 Meter) 791414831001M (1 Meter)
• 791414OS2D002MR3 (2 Meter) 791414831002M (2 Meter)
• 791414OS2D003MR3 (3 Meter) 791414831003M (3 Meter)
• 791414OS2D004MR3 (4 Meter) 791414831004M (4 Meter)
• 791414OS2D005MR3 (5 Meter) 791414831005M (5 Meter)
• 791414OS2D010MR3 (10 Meter) 791414831010M (10 Meter)
• 791414OS2D015MR3 (15 Meter) 791414831015M (15 Meter)
• 791414OS2D020MR3 (20 Meter) 791414831020M (20 Meter)
• 791414OS2D030MR3 (30 Meter) 791414831030M (30 Meter)
Custom lengths available upon request.

NOTES: Non-standard colors are special order custom cables and require a 5-7 day lead time. These are Non-Cancelable and Non-Returnable once they go into production.

Dust caps on the connector tips are there for the protection of the fiber in the ferrules.
