HD8² Cassette, 48 Strand, OM3, 4 Port MTP® Elite 12F (Male) Front to 2 Port MTP® Elite 24F (Male) Rear, Aqua, Straight

Made To Order, Normal lead-time 7 - 10 days, after Drawing Approval


0.20 LBS

Customer Service
Need Help?

Speak to one of our experts.

HD8² Cassette, 48 Strand, Multimode OM3 50/125um, Front Panel includes 4 Port Aqua MTP® Elite 12 Fiber Male, Rear Panel includes 2 Port Aqua MTP® Elite 24 Fiber Male, Straight (Type A) Pinout
Product Specification:
Front Panel Connector
MTP/UPC Elite 12 Fiber Rear Panel Connector
MTP/UPC Elite 24 Fiber
Ferrule Type Front

Ferrule Type Rear

Front Cassette Ports
4 Rear Cassette Ports
Insertion Loss Maximum Side A
≤0.35dB Insertion Loss Maximum Side B
Insertion Loss Typical
0.10dB Insertion Loss Typical
Return Loss ≥20dB Return Loss ≥20dB
==================== ==================
Cable Type
OM3 50/125μm Wavelength 850/1300nm
Fiber Count 48 Fiber Grade Corning ClearCurve Glass
Polarity Straight (Type A) Cable Outer Diameter 250um
Cable Jacket N/A Sub Unit Outer Diameter N/A
Bend Radius, No Load
10x cable overall diameter Bend Radius, Load
15x cable overall diameter
==================== ==================
1 GbE Distance Max. 10 GbE Distance Max. 40 GbE Distance Max. 100 GbE Distance Max.
1,100 Meters 300 Meter 100 Meter 100 Meter
Operating Temperature 0° to 70°C (32° to 158°F) Storage Temperature -40° to 70°C (-40° to 158°F)
